4G LTE ANTENNA
4G LTE 5dBi Magnetic Antenna 310mm
Magnetic mount 4G LTE antenna for routers, gateways and industrial terminals.
Model: Available on Request
Frequency: 698-960 / 1710-2700 MHz
Gain: 5 dBi
Connector: SMA
Product Overview
4G LTE 5dBi Magnetic Antenna 310mm for OEM/ODM wireless projects, covering 698-960 / 1710-2700 MHz with 5 dBi gain and 50 Ω nominal impedance. Connector options: SMA. Minsta supports project-specific antenna customization.
Key Features
- Frequency range: 698-960 / 1710-2700 MHz
- Gain: 5 dBi
- Connector: SMA
- Impedance: 50 Ω
- OEM/ODM customization available
Specifications
| Model | Available on Request |
|---|---|
| Frequency Range | 698-960 / 1710-2700 MHz |
| Gain | 5 dBi |
| VSWR | 698-960 <2; 1710-2700 <6 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Maximum Power | 50 W |
| Dimensions | 310 mm |
| Connector | SMA |
| Operating Temperature | -40°C to +80°C |
| Material | To Be Confirmed |
| Customization | OEM / ODM available |
Applications
Cellular routers, gateways, IoT terminals, telemetry devices and industrial wireless equipment.
Customization Options
Connector, cable, frequency, housing, labeling and packaging can be customized according to project requirements.
