5G ANTENNA
5G 5dBi Paddle Antenna 193.5mm
Slim external 5G paddle antenna for cellular gateways and wireless equipment.
Model: Available on Request
Frequency: 698-960 / 1710-5000 MHz
Gain: ≤5 dBi
Connector: SMA
Product Overview
5G 5dBi Paddle Antenna 193.5mm for OEM/ODM wireless projects, covering 698-960 / 1710-5000 MHz with ≤5 dBi gain and 50 Ω nominal impedance. Connector options: SMA. Minsta supports project-specific antenna customization.
Key Features
- Frequency range: 698-960 / 1710-5000 MHz
- Gain: ≤5 dBi
- Connector: SMA
- Impedance: 50 Ω
- OEM/ODM customization available
Specifications
| Model | Available on Request |
|---|---|
| Frequency Range | 698-960 / 1710-5000 MHz |
| Gain | ≤5 dBi |
| VSWR | ≤2.5 |
| Impedance | 50 Ω |
| Polarization | Linear |
| Maximum Power | To Be Confirmed |
| Dimensions | 193.5 × 44.5 × 9 mm |
| Connector | SMA |
| Operating Temperature | -40°C to +85°C |
| Material | To Be Confirmed |
| Customization | OEM / ODM available |
Applications
Cellular routers, gateways, IoT terminals, telemetry devices and industrial wireless equipment.
Customization Options
Connector, cable, frequency, housing, labeling and packaging can be customized according to project requirements.
