EMBEDDED 5G ANTENNA
5G LTE 5dBi FPC Antenna 120×50mm
Flexible FPC antenna for embedded 5G and LTE applications requiring low-profile installation.
Model: WL-5GIF12050
Frequency: 600-960 / 1710-5000 MHz
Gain: 5 dBi
Connector: SMA / IPEX / U.FL
Product Overview
5G LTE 5dBi FPC Antenna 120×50mm for OEM/ODM wireless projects, covering 600-960 / 1710-5000 MHz with 5 dBi gain and 50 Ω nominal impedance. Connector options: SMA / IPEX / U.FL. Minsta supports project-specific antenna customization.
Key Features
- Frequency range: 600-960 / 1710-5000 MHz
- Gain: 5 dBi
- Connector: SMA / IPEX / U.FL
- Impedance: 50 Ω
- OEM/ODM customization available
Specifications
| Model | WL-5GIF12050 |
|---|---|
| Frequency Range | 600-960 / 1710-5000 MHz |
| Gain | 5 dBi |
| VSWR | 600-960 ≤2; 1710-5000 ≤3 |
| Impedance | 50 Ω |
| Polarization | Vertical |
| Maximum Power | 50 W |
| Dimensions | 120 × 50 mm |
| Connector | SMA / IPEX / U.FL |
| Operating Temperature | -40°C to +80°C |
| Material | FPC |
| Customization | OEM / ODM available |
Applications
Cellular routers, gateways, IoT terminals, telemetry devices and industrial wireless equipment.
Customization Options
Connector, cable, frequency, housing, labeling and packaging can be customized according to project requirements.
